2011-2017 6.7L Ford F250 F350 F450 EGR w/ Coolant Line

Here’s the detailed technical breakdown for the 2011-2017 Ford 6.7L Power Stroke EGR Delete Kit, including critical installation procedures and compliance considerations:

⚠️ 6.7L Power Stroke-Specific Warnings

1. Dual EGR System Alert:

   • These engines use hot-side (high-pressure) + cold-side (low-pressure) EGR

   • Kit must address both circuits to prevent CEL and derate

2. Coolant Flow Critical:

   • EGR cooler handles 40% of coolant circulation to turbo

   • Requires complete coolant bypass to prevent turbo overheating

3. Sensor Dependencies:

   • Retain EGR temperature sensors (fake signals needed)

   • Keep DPF differential pressure sensor connected

🔧 Kit Components & Specifications

🛠️ Professional Installation Guide

Required Tools:

• Torx T30 (EGR valve bolts)

• 10mm Flare Nut Wrench (coolant lines)

• Infrared Thermometer (coolant system verification)

Critical Steps:

1. Coolant System Procedure:

   • Drain to degas bottle mid-level

   • Install coolant crossover block plates before EGR removal

   • Refill with Ford VC-3-B2 coolant only

2. Sensor Management:

   • Leave all sensors plugged in

   • Install 3.9kΩ resistor on EGR temp sensor circuit

   • Retain MAP sensor in stock location

3. Exhaust Side Mods:

   • Apply Copper RTV to up-pipe flange

   • Inspect VGT actuator for smooth operation

⚡ Performance Data

Proven Benefits:

• Eliminates EGR cooler failures ($3,500 dealer repair)

• Prevents turbo coking from soot accumulation

• Restores 8-12mpg in city driving

🚨 Legal Consequences

Dealer Impacts:

• Activates “Permanent Tamper Flag” in IDS

• Voids entire emissions warranty (5yr/50k mi)

💻 Mandatory Tuning Requirements

Required PCM Changes:

• Disable EGR valve PIDs (SPN 102)

• Recalibrate VGT control tables (+12% duty cycle)

• Modify MAF transfer function

Recommended Tuners:

• SCT LiveWire TS+ (with custom tuning)

• H&S Mini Maxx (pre-loaded 6.7L files)

• EZ Lynk with AutoCal

🔩 Supporting Upgrades

1. Mishimoto Intercooler (MMINT-F6D-13)

2. BD Diesel EGR Cooler Bypass Kit

3. Edge CTS3 Monitoring System

🛑 Compliance Alternatives

For street-legal operation:

• Ford OEM EGR Service Kit (BC3Z-9P456-A)

• Banks Derringer EGR Throttle Plate

Pro Tip

Post-Installation:

1. Reset KAM (Keep Alive Memory)

2. Perform 50-mile calibration drive

3. Monitor EGTs closely for first 1,000 miles
